Post Your DVB-T2 Settings (no discussions here)

This thread is meant for successful DVB T2 users to post your TV model / STB / antenna / location so others can emulate you. Cheers

THERE WILL BE NO DISCUSSIONS HERE. Thanks

The format with prices of the antenna / STB if you have it:

TV MODEL (and size):

LOCATION:

ANTENNA:

SET TOP BOX:

Additional info (channels received, tips etc)


Please post pictures if possible.

Let's help everyone get into DVB T2 !

Cheers
VideoOne2 likes this.
__________________
POST YOUR QUESTIONS INSTEAD OF SENDING A PM



Use the Search Button and Read the Stickies!




My home theatre gear and my blog:

http://peteswrite.blogspot.sg/2016/0...arch-2016.html

Last edited by petetherock; 13-01-2014 at 12:35 PM..
petetherock is offline   Reply With Quote
Old 29-12-2013, 09:41 AM   #2
Junior Member

Join Date: Aug 2000
Posts: 9
My set up

My set up

TV MODEL (and size): SONY KDL-40NX710 (40 inch) (almost 3 yrs old)

LOCATION: KULAI, JOHOR (50km from Spore)

ANTENNA: EXTERNAL rooftop VHF/UHF With booster

SET TOP BOX: DRACO DIGITAL FULL HD DVB-T/T2 Receiver

Able receive all T and T2 transmissions in HD and SD clearly.
STB's HDMI CEC interfere with my SONY sound bar. Use HDMI to DVI and DVI to HDMI female to cut out the CEC signal and everything works fine.
seehong is offline   Reply With Quote
Old 29-12-2013, 01:21 PM   #3
Moderator

sunsetbay's Avatar

Join Date: Jul 2000
Posts: 39,307
TV MODEL (and size): 47LA623T

LOCATION: Tamp

ANTENNA: HDB MATV

SET TOP BOX: Nil

Additional info (channels received, tips etc)

Able to recv all T2 HD & SD channels, 100% signal strength & quality~ T channels no prob since im able to recv since it started~ Also tested with diy CD case antenna, unable to receive as expected~

GPGT for T2 channels~

Spoiler!
__________________
۩₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪۩

sunsetbay is online now   Reply With Quote
Old 29-12-2013, 04:02 PM   #4
High Supremacy Member

Adi Dassler's Avatar

Join Date: Mar 2010
Posts: 27,017
TV MODEL (and size): Old CRT tv toshiba

LOCATION: Sembawang

ANTENNA: indoor rabbit ear antenna

SET TOP BOX: DRACO DIGITAL FULL HD DVB-T/T2 Receiver

Able to detect all sg FTA channels but not for ch8.

When I adjust my antenna at a certain angle to receive ch8, the rest of the channels I'm unable to receive..

Can anyone help? What's wrong?

Last edited by Adi Dassler; 01-01-2014 at 01:05 PM..
Adi Dassler is offline   Reply With Quote
Old 29-12-2013, 07:15 PM   #5
lax
Master Member

Join Date: May 2001
Posts: 3,472
TV model LG 55" LA740T
no need STB
Antenna - ordinary 25 year old roof top 16 element UHF antenna 27db gain
Coxial replaced with RG6 category
Booster thrown in since I have it lying in the house to compensate for aircraft n bike interference just make sure frequency respond is up to 1000 mhz
location Hougang
signal so far all 90 - 100%
lax is offline   Reply With Quote
Old 29-12-2013, 09:42 PM   #6
Master Member

Join Date: May 2011
Posts: 2,727
TV MODEL (and size): 40" Samsung Smart & 1999 20" Philips CRT (bedroom).

LOCATION: Bishan near Bishan Park

ANTENNA: Condo MATV & antigue indoor telescopic for testing (see picture below)

SET TOP BOX: Draco

Additional info: Perfect reception for all T2 and T broadcasts using matv (condo provided chan 38 reception when Sports/ City channel existed. Signal Intensity 99%, Signal Quality 98% throughout chans 27, 29 , 31, 33 and 38. [Hall and bedroom]

Using indoor antenna for both tv tested one after the other, 27, 29, 31 and 33 achieved SI/SQ as good as matv. For chan 38, both indicators exceeded 90%. Again perfect reception.

Tips: With indoor antenna, it is advisable to scan manually, channel by channel, in areas where indoor signal may not be so strong. The signal strength is then visually available to assist in locating the best spot.
Where the angle of antenna elements can be adjusted, straighten them as shown in the pic, with overall length about 0.25 to 0.3m. Orientate whole antenna in different angle and direction.

Use extension coax cable for more flexibility in locating the best spot.


Last edited by mrsun18; 30-12-2013 at 08:25 PM..
mrsun18 is offline   Reply With Quote
Old 29-12-2013, 11:18 PM   #7
Senior Member

oric1's Avatar

Join Date: Dec 2001
Posts: 1,580
TV MODEL (and size): Samsung 55" Series 7 (2013 model) LED Smart TV - UA55F7500BK

LOCATION: Bishan North

ANTENNA: Daiyo HD Digital Indoor Antenna EU1702

GET FROM (and price): Courts & NTUC Xtra ($64)

SET TOP BOX: Not using as the TV comes with built-in DVB-T2/C tuner

Additional info (channels received, tips etc): Remember to select Auto Tuning. I did tried manual tuning and it couldn't find the channels.

The antenna is indoor with curtains drawn and yet still able to received full signal (100% as indicated by the TV built-in diagnostic).

Please post pictures if possible.






Last edited by oric1; 29-12-2013 at 11:27 PM..
oric1 is offline   Reply With Quote
Old 30-12-2013, 01:31 AM   #8
Senior Member

Join Date: Aug 2005
Posts: 527
TV MODEL (and size): LG 55LA740T 55"

LOCATION: Yew Tee

ANTENNA: Daiyo EU1702

SET TOP BOX: NIL

Additional info (channels received, tips etc): Received all 7 FTA Channels with 100% Signal. HD5, HD8 Suria HD VAS HD, CNA, CH U, OKTO.
JazzFreaky is offline   Reply With Quote
Old 01-01-2014, 10:00 PM   #9
Senior Member

Join Date: Jun 2006
Posts: 569
TV MODEL (and size): Panasonic non DVB-T2 TV

LOCATION: CCK

ANTENNA: Fish Bone VHF/UHF

SET TOP BOX: Draco HDT2-7300

Additional info (channels received, tips etc)
DVB-T: Ch 5 HD, Ch 5 SD, Ch 8 SD, CNA SD
DVB-T2: Ch 5 HD, Ch 8 HD, Vas HD, Suria HD, CNA SD, Ch U SD, Okto SD, Channel 8+1 (test channel), Test 1 (test channel), RCTI SD (weak signals), Global TV SD (weak signals), MNC TV SD (weak signals)
chuppachop is offline   Reply With Quote
Old 06-01-2014, 01:41 PM   #10
Junior Member

Join Date: Jun 2010
Posts: 2
Smile Tanglin Halt Road, Commonwealth, Highfloor

TV MODEL (and size): LG 42" LCD - Analog TV with HDMI inputs (2008 model)

LOCATION: Commonwealth MRT (high floor, 35+_

ANTENNA: NUSHI VHF/UHF with booster (~$24, +33dB boosting?)

SET TOP BOX: Draco HDT2-7300

Additional info (channels received, tips etc)
DVB-T: Ch 5 HD, Ch 5 SD, Ch 8 SD, CNA SD
DVB-T2: Ch 5 HD, Ch 8 HD, Vas HD, Suria HD, CNA SD, Ch U SD, Okto SD, Channel 8+1 (test channel), Test 1 (test channel),
putumayam1 is offline   Reply With Quote
Old 06-01-2014, 05:17 PM   #11
Member

Join Date: Feb 2012
Posts: 300
TV MODEL (and size): Sony 47W804A

LOCATION: Marine Parade

ANTENNA: No brand antenna as shown in this post (Digital TV (DVB T2) in Singapore [consolidated]) ($12.90 from neighborhood DIY store)

SET TOP BOX: None (TV is DVB-T2)

Additional info (channels received, tips etc)
Channels: Ch 5 HD, Ch 5 SD, Ch 8 HD, Ch 8 SD, CNA SD, Vas HD, Suria HD, Ch U SD, Okto SD, Channel 8+1, Test 1, etc.



Last edited by pustefix; 13-01-2014 at 08:58 AM..
pustefix is offline   Reply With Quote
Old 06-01-2014, 10:30 PM   #12
Supremacy Member

Join Date: Mar 2002
Posts: 6,517
TV MODEL (and size): Sony 42" W674A

LOCATION: Sembawang

ANTENNA: Daiyo EU1702

SET TOP BOX: NIL as TV has inbuilt T2 digital tuner

Additional info (channels received, tips etc): Received all 7 FTA Channels with 95-100% signal. HD5, HD8 Suria HD VAS HD, CNA, CH U, OKTO. Manual scanning.
__________________
21.5" iMac iCore5 2.5Ghz 4GB RAM + WD 1TB My Book + WD 640GB X 1 + WD 1TB X 1
faithsilence is offline   Reply With Quote
Old 07-01-2014, 04:48 PM   #13
Member

willie2005's Avatar

Join Date: Nov 2005
Posts: 334
TV MODEL (and size): Sony 65"

LOCATION: Tampines Central ( Ground Floor )

ANTENNA: Margon Combo 5.1

SET TOP BOX: Draco HDT2-7300

Additional info (channels received, tips etc)

Ch 5 HD, Ch 8 HD, Vas HD, Suria HD, CNA SD, Ch U SD, Okto SD
willie2005 is offline   Reply With Quote
Old 07-01-2014, 05:47 PM   #14
Senior Member

leongws's Avatar

Join Date: May 2003
Posts: 1,588
TV MODEL (and size): Sony 46" KDL-46EX710

LOCATION: Yishun

ANTENNA: Margon Home 2.0

SET TOP BOX: Draco HDT2-7300

Additional info (channels received, tips etc): Booster/Amplifier needed. Received all 7 FTA Channels with above 95% signal. HD5, HD8, Suria HD, VAS HD, CNA, CH U, OKTO + 2 test channels. Auto scanning.

Last edited by leongws; 07-01-2014 at 07:06 PM..
leongws is offline   Reply With Quote
Old 11-01-2014, 08:51 AM   #15
Master Member

Join Date: Sep 2006
Posts: 2,640
TV MODEL (and size): LG 42LA623T 42"

LOCATION: Tiong Bahru

ANTENNA: Daiyo HD Digital Indoor Antenna EU1702

TOP BOX: Nil

Additional info (channels received, tips etc)
DVB-T2: Ch 5 HD, Ch 8 HD, Vas HD, Suria HD, CNA SD, Ch U SD, Okto SD, Channel 8+1 (test channel), Test 1 (test channel)
yiptw89 is offline   Reply With Quote
